Closing the lift truck material loop.

In this anniversary issue, Gay Sutton looks behind the scenes to see what happens to that trusted old warhorse – the forklift truck – when it’s scrapped, and how elements are resurfacing in many unexpected places.

Growing demand for resources – materials and power – is spurring countries around the globe to migrate to a new ethos: that of the circular economy, where the two ends of the old linear take-make-consume-and-dispose lifecycle are brought together to form a self-sufficient loop by recycling. In the EU, this has been enshrined in the European Commission’s 2050 vision and summarised as ‘living well within the limits of the planet’.

So, with a raft of EU environmental and recycling legislation in place, what happens to your old forklift truck when it reaches the end of its life?

The heroes of the moment

The forklift dealers are the heroes of the first phase of scrapping and recycling. “The forklift truck dealers are very resourceful and recycle as much as possible themselves,” explained Duncan Nealon, Chairman of the Fork Lift Truck Association. A truck that is returned to the dealer for scrap will be broken down bit by bit for spares. Anything that can be reused and recycled, such as gearboxes or drive motors, will be kept, repaired or remanufactured, and then put back into use. Dealers are the masters of recycling viable components.

EU regulations are then very strict for certain streams of waste, each of which is sent to a specialist company to be dealt with. So engine oil and hydraulic oil are drained from the carcass by the dealers and sent for disposal, while batteries and catalytic converters, containing a number of hazardous components, are also sent to companies with the capability to recycle and dispose of them.

What is left is essentially the scrap metal – the chassis and the counterweight with the odd extra such as wiring, seat material and straps – and this then goes to a scrap metal dealer.

That’s the last a forklift user or dealer will see of it. Or is it? Let’s now look a bit deeper below the surface and see what happens next.

Scrap metal

Scrap metal enters what can be described as a pyramid industry with small companies at the bottom and large multinationals at the top. Explained simply, the scrap metal starts its progress at a shredding plant where materials are sorted then broken and shredded.

The next step uses huge magnets to extract the iron and steel from non-ferrous metals such as copper and aluminium, as well as what Howard Bluck, Technical Director at the British Metals Recycling Association, describes as ‘shredder fluff’. Further separation can be achieved manually, or by using electrical currents, high pressure air flow and liquid floating systems. Iron, steel and non-ferrous metals are then compacted into bales and sent for   processing into new raw materials. Other items such as cloth and paper are baled for use elsewhere.

Although theoretically most metals can be continually recycled, there is always the risk that small amounts of other materials such as copper wiring are still attached to the metal when it is magnetically separated. This leads to so-called ‘tramp elements’ entering the steel melt, and these can ultimately change the characteristics of the final steel output.

“And once you get a particular percentage of copper in steel you start to get fissures and fractures at the microscopic level around the grain boundaries of the copper embedded in the steel,” Howard said. Ultimately, there will be a point at which the steel can no longer be used for high-quality products, and one of the next major steps in improving the recycling process, he believes, will be discussing how to tackle this quality issue.

Other important elements

Disposal of old batteries is covered under the 2006 Batteries Directive. Battery technology is moving on quickly and recycling processes are changing with it. Different types of batteries are handled in different ways, but they are generally stripped before crushing so that the lead, plastic, acid, cadmium and other elements can be safely removed and reused.

Catalytic converters are part of the new generation of products that have been designed for easy recycling, and as well as the regular ferrous and non-ferrous metals, valuable minerals such as platinum, palladium and rhodium can be extracted and recycled.

Currently, the majority of forklifts being scrapped are relatively old and have few electrical or electronic parts, but as the more modern generation of forklift begins to trickle through the system its electronic/computer-based elements will need scrapping, and handling very differently.

Today’s recycling industry is continuously improving its ability to process and recycle these materials, and increasingly developing methods for extracting valuable metals and rare earths for use elsewhere in industry, finding uses for even the most mundane of materials such as seatbelt webbing.
